Frame

New Frame, Updated Geometry and Hydroformed tubing, Tapered headtube, 6061 Alloy, full length internal routing, replaceable derailleur hanger, integrated mount for 40mm direct-mount 2-bolt kickstand

Headset

Semi Integrated ZS44/28.6 ZS56/40

Frame Axle Spacing

135x9mm

Axle Specification

QR

Hanger Type

HANGER 22

Fork

Rock Shox Recon Silver TK, Air, Remote, BOOST, 100mm Travel, Tapered, Fender Compatible

Fork Travel

100mm

Wheelset

Surface Custom

Hubs

F: Shimano Centerlock, 32h MT400B 110x15mm Thru-axle

R: Shimano Centerlock, 32h TX505 135mm x 10 QR

Rims

Surface Asymmetrical Double wall alloy, 23mm Internal Width, Tubeless Ready

Tyres

REKON RACE 29 X 2.35 TR EXO 60TPI

Max Tyre Size

2.4"

Crankset

SRAM SX Eagle DUB 34T

Max Chainring Size

36T

Bottom Bracket & Type

BSA73

Shifter(s)

SRAM SX Eagle, 12 spd

Front Derailleur

N/A

Rear Derailleur

SRAM SX 12pd Eagle

Cassette

SX Eagle 11-50t

Chain

SRAM

Brakes

Tektro MD-M275 Hydraulic Disc Brakes

Rotors

F: Shimano SM-RT10 180mm

R: Shimano SM-RT10 180mm

Grips

Surface

Handlebar

Alloy, Oversize. 9deg backsweep, 5deg rise

Stem

Alloy 31.8mm, 10deg rise

Saddle

Surface Ergo, Steel Rails

Seat Post

Alloy 30.9mm, micro adjust

Seatpost Clamp

Alloy

Pedals

One Piece Alloy

Bike Weight

14.46kg (including pedals 370g)

RIDER WEIGHT LIMIT

120kg - combined weight of bike and rider (including all kit).
