Frame

Double Butted Hydroformed 6061 alloy Frame with Internal Battery.

Headset

FSA NO.42/ACB-1-A

Frame Axle Spacing

135x9mm

Axle Specification

QR

Hanger Type

HANGER 25

Motor

Shimano E7000

Battery

Shimano E8035 504Wh Battery

Charger

Shimano EC-E6002

Display

Shimano E6100

Switch

Shimano SW-E6010.

Fork

SR Suntour NEX HLO DS 700, 63mm, Hydraulic Lockout

Fork Travel

63mm

Wheelset

SURFACE 700 C Custom

Hubs

Front: Shimano TX505 100x9mm, Centrelock,

Rear: Shimano TX505-8 135x9mm, Centerlock

Rims

SURFACE 700 C" Symmetrical Alloy Rim, Tubeless Ready

Tyres

Schwalbe Marathon Plus 28x1.75, SmartGuard, E-50

Max Tyre Size

47C or 2.0"

Crankset

Shimano E6100 Crankarm

Max Chainring Size

38 T

Shifter(s)

Shimano Deore 10-Speed

Rear Derailleur

Shimano DEORE 10-Speed Rear Derailleur DA 36T

Cassette

Shimano HG-50-10 10 Speed 11-36t

Chain

KMC X10 10 Speed

Brakes

Shimano DEORE BL-T6000, Rotors: Shimano RT10 180/160mm

Rotors

F: Shimano RT10 180mm

R: Shimano RT10 160mm

Grips

SBC Lockon

Handlebar

SURFACE Alloy, Dia:31.8mm,

Stem

SURFACE Alloy Stem, 31.8mm

Saddle

Surface, double density with rubber base.

Seat Post

SURFACE Alloy, Dia:30.9mm

Seatpost Clamp

Alloy QR Clamp

Pedals

Not included

Bike Weight

22 kg

RIDER WEIGHT LIMIT

120kg - combined weight of bike and rider (including all kit).

Lock

Integrated rear wheel lock solution
