Frame

Aluminium E - MTB frame, 720wh battery compatible. Shimano STEPs EP8, E8000 or E7000 motor. The geometry is designed for the typical Fat Bike enthusiast making the ride experience feel comfortable on those long rides. This frame has tyre clearance for 26 x 4.8" tyres.

Headset

Token TK035A-15 Sealed Bearing

Frame Axle Spacing

197x12mm

Axle Specification

229x12mm P1.75

Hanger Type

Hanger 03

Motor

Shimano EP8 Drive Unit, Mid-Position, 25km/h, 85N.m Torque

Battery

Darfon 720Wh, 36V, 20Ah Li-Ion, 3.8Kg Weight

Charger

Darfon Smart Plus, 100-240V, 4A, EU use

Display

Shimano E7000 Screen Display 31.8mm

Switch

Shimano SW-EM7000, Left

Fork

SBC Carbon, 26" Rigid, 150x15mm Thru Axle

Wheelset

Sun Ringle Mulefüt 26'' FATBike Custom Wheelset

Hubs

F: SUNringlé SRC 150x15mm, 6 Bolt

R: SUNringlé SRC 197x12mm, 6 Bolt

Rims

F: SUNringlé Mulefüt 80SL, Tubeless Ready

R: SUNringlé Mulefüt 80SL, Tubeless Ready

Tyres

F: VEE Tire Bulldozer 26x4.7", Foldable, Tubeless Ready, 72TPI

R: VEE Tire Bulldozer 26x4.7", Foldable, Tubeless Ready, 72TPI

Max Tyre Size

4.8"

Crankset

Alloy Fat Bike Crank, EP8

Max Chainring Size

38T

Shifter(s)

R: Shimano SL-M5100-R Deore, 11 Speed Rapidfire Plus

Rear Derailleur

Shimano RD-M5100 Deore, 11 Speed

Cassette

Shimano CS-M5100 Deore, 11 Speed 11-51T

Chain

Shimano CN-HG601-11, 11spd

Brakes

F: Shimano MT200, Resin Pads

R: Shimano MT200, Resin Pads

Rotors

F: Shimano SM-RT10 180mm, 6-Bolt

R: Shimano SM-RT10 180mm , 6-Bolt

Grips

SBC Lockon Grip

Handlebar

SURFACE Alloy, Dia:31.8mm, Backsweep:9°, Rise 5mm

Stem

SURFACE Alloy, 31.8mm, Rise 6°, with stainless steel bolts

Saddle

SURFACE E-BIKE saddle, Black, Cromo Rails

Seat Post

SURFACE Alloy

Seatpost Clamp

SURFACE QR Clamp

Bike Weight

24,2kg (M size, no pedals)

RIDER WEIGHT LIMIT

120kg - combined weight of bike and rider (including all kit).
